Industrial Distributed IO Controller Module IO-ECT-8DI
IO-ECT-8DI
IO-ECT-8DI is an EtherCAT protocol IO slave device that supports 8-way switch input. This distributed IO controller is convenient for distributed deployment, has a small size, saves installation space, and is suitable for more scenarios.
Description
Features
- Supports 8-way PNP or NPN switch input
- Supports EtherCAT Slave Protocol
- Integrated design, compact structure, convenient for distributed installation and deployment
- Based on high-performance EtherCAT dedicated communication chip, the acquisition response speed is fast
- Compact and small in size, easy to expand, requires minimal cable usage, and is convenient to use and maintain
- Built in dedicated filtering circuit, strong communication anti-interference, and stable system operation
Usage
Power battery production line, household appliance/3C mixed flow production line, automobile production line, machine tools, automation equipment, AGV, etc
Application scenario
Technical features
|
Physical Parameters |
Bus Protocol |
EtherCAT slave station |
|
Data Transmission Interface |
2 x M8 socket, 4-pin |
|
|
Transfer Rate |
100Mb/s |
|
|
Transfer Distance |
100m(distance between stations) |
|
|
Electrical Isolation |
500V |
|
|
Switching Input |
Switching Channel |
8 |
|
Response Time |
≤3ms |
|
|
Signal Type |
PNP |
|
|
Single Channel Sampling Current |
3mA |
|
|
Isolation and Voltage Resistance |
AC 500V |
|
|
Channel Indicator Light |
Green LED light |
|
|
Maximum Load of Power Supply |
DC24V 0.5A |
|
|
Power Supply Parameters |
Rated Voltage |
24 VDC (-15%/+20%) |
|
Rated Current |
120 mA(8-way DI fully operational) |
|
|
Maximum Current |
4A |
|
|
Application Environment |
Working Temperature |
-25℃~+60℃ |
|
Storage Temperature |
-25℃~+85℃ |
|
|
Working Humidity |
5%~95%RH(No condensation) |
|
|
Protection Grade |
IP53 |
|
|
Impact Resistance |
GB/T 2423.10-2008/IEC 60068 -2 -6:1995 |
|
|
Certification |
CE, FCC, RoHS2.0 |
|
|
Accessories |
Connectors, cables, etc |
Dimension (Unit: mm)
